Sliding doors

Large glass panels with smooth sliding operation, designed to maximize daylight and outdoor connection.

Tilt & turn windows

Casement doors

Sliding doors

Sliding doors

Profiles

Aluprof

MB77HS

Aluminum

Aluprof MB-77HS is a top-tier lift-and-slide aluminium system designed for expansive panoramic glazing in residential and commercial spaces. The sash has a depth of 77 mm, and the frame ranges from 174 to 271 mm, depending on whether it’s a 1-, 2-, or 3-track setup. It supports triple-glazed units up to 58.5 mm thick and allows for impressive sash sizes — up to 3.3 m in height and 3.2 m in width — while maintaining outstanding structural rigidity. The HI variant features an ultra-slim 47.5 mm central mullion, offering a nearly uninterrupted glass wall and maximum daylight. The system achieves excellent thermal performance — with Uw values starting from 0.84 W/m²K — thanks to wide, glass-fiber reinforced polyamide thermal breaks and multi-layer central gaskets. Sound insulation reaches up to 48 dB. Smooth sliding is ensured even with sashes weighing up to 600 kg, with optional automation and smart home integration. A low threshold (flush with the floor) is ideal for barrier-free access. Weather- and UV-resistant, the system lasts 60+ years. Aluminium is fully recyclable and finished with eco-friendly coatings. MB-77HS is perfect for villas, penthouses, conservatories, hotels, and restaurants where aesthetics meet performance.

Aluprof MB-77HS is a top-tier lift-and-slide aluminium system designed for expansive panoramic glazing in residential and commercial spaces. The sash has a depth of 77 mm, and the frame ranges from 174 to 271 mm, depending on whether it’s a 1-, 2-, or 3-track setup. It supports triple-glazed units up to 58.5 mm thick and allows for impressive sash sizes — up to 3.3 m in height and 3.2 m in width — while maintaining outstanding structural rigidity. The HI variant features an ultra-slim 47.5 mm central mullion, offering a nearly uninterrupted glass wall and maximum daylight. The system achieves excellent thermal performance — with Uw values starting from 0.84 W/m²K — thanks to wide, glass-fiber reinforced polyamide thermal breaks and multi-layer central gaskets. Sound insulation reaches up to 48 dB. Smooth sliding is ensured even with sashes weighing up to 600 kg, with optional automation and smart home integration. A low threshold (flush with the floor) is ideal for barrier-free access. Weather- and UV-resistant, the system lasts 60+ years. Aluminium is fully recyclable and finished with eco-friendly coatings. MB-77HS is perfect for villas, penthouses, conservatories, hotels, and restaurants where aesthetics meet performance.

Frame depth: 174–271 mm
Sash depth: 77 mm
Glazing thickness: up to 58.5 mm
Maximum sash size: 3300 × 3200 mm
Thermal insulation: Uw from 0.84 W/m²K
Sound insulation: up to Rw 48 dB
Air permeability: Class 4 (EN 12207)
Watertightness: Class 9A (EN 12208)
Wind load resistance: Class C4/B4 (EN 12210)
Burglary resistance: up to RC3
Threshold: low, barrier-free
Material: thermally broken aluminium

Aluplast

Smart-Slide

PVC

Aluplast Smart-Slide is an innovative PVC sliding door system with a frame depth of 70 mm and sash depth of 44 mm. Its compact and lightweight design makes it elegant and easy to operate. It supports glazing up to 41 mm thick, achieving thermal insulation values as low as Uw 0.77 W/m²K, comparable to top-class window systems. The multi-chamber profile and wide perimeter seals provide excellent thermal and sound insulation (up to Rw 45 dB). A unique sash-to-frame pressure mechanism ensures high airtightness, protecting against drafts, moisture, and dust. High-quality rollers and hardware enable smooth, effortless operation — even of large panels — with a low threshold option for accessibility. Panels up to 1.5 m wide and 2.3 m high make it ideal for terraces, balconies, and garden access with a panoramic effect. Slim profiles allow more natural light and a modern aesthetic. A wide range of Aluplast laminations is available — woodgrain, matte, metallic, and Bi-Color. Made with lead-free CaZn stabilizers, the profile meets European environmental standards. PVC is highly resistant to fading, cracking, and weather extremes, with a lifespan of over 40 years. Smart-Slide is a smart alternative to bulky aluminum systems, offering better insulation, smooth operation, and a sleek, modern appearance.

Aluplast Smart-Slide is an innovative PVC sliding door system with a frame depth of 70 mm and sash depth of 44 mm. Its compact and lightweight design makes it elegant and easy to operate. It supports glazing up to 41 mm thick, achieving thermal insulation values as low as Uw 0.77 W/m²K, comparable to top-class window systems. The multi-chamber profile and wide perimeter seals provide excellent thermal and sound insulation (up to Rw 45 dB). A unique sash-to-frame pressure mechanism ensures high airtightness, protecting against drafts, moisture, and dust. High-quality rollers and hardware enable smooth, effortless operation — even of large panels — with a low threshold option for accessibility. Panels up to 1.5 m wide and 2.3 m high make it ideal for terraces, balconies, and garden access with a panoramic effect. Slim profiles allow more natural light and a modern aesthetic. A wide range of Aluplast laminations is available — woodgrain, matte, metallic, and Bi-Color. Made with lead-free CaZn stabilizers, the profile meets European environmental standards. PVC is highly resistant to fading, cracking, and weather extremes, with a lifespan of over 40 years. Smart-Slide is a smart alternative to bulky aluminum systems, offering better insulation, smooth operation, and a sleek, modern appearance.

Frame depth: 70 mm
Sash depth: 44 mm
Glass thickness: up to 41 mm
Maximum sash dimensions: 1500 × 2300 mm
Thermal insulation: Uw from 0.77 W/m²K
Air permeability: Class 4 (EN 12207)
Watertightness: Class 9A (EN 12208)
Wind load resistance: Class B3 (EN 12210)
Sound insulation: up to Rw 45 dB
Burglary resistance: up to RC2 (depending on configuration)
Optional features: low threshold, soft-close system, Bi-Color finishes

Aluplast

HST-85

PVC

Aluplast HST 85 is a modern lift-and-slide PVC system with a 197 mm frame and 85 mm sash depth. It’s specifically designed for large panoramic openings — up to 6.5 meters wide and 2.7 meters high. Slim visible profile parts and support for glazing up to 51 mm create a full "glass wall" effect with maximum natural light. The 6-chamber sash structure and Uw from 0.77 W/m²K meet the standards for energy-efficient and passive buildings. Durable EPDM seals provide reliable protection against drafts, moisture, and external noise — up to Rw 47 dB. High-performance lift-and-slide hardware allows smooth operation of sashes weighing up to 400 kg, easily operated with one hand. The system also features a low threshold starting from 20 mm, ideal for children, seniors, and accessibility needs. The PVC profile is resistant to UV, weather, deformation, and mechanical stress, with a lifespan of 40–50 years. Over 40 laminate finishes are available — including woodgrain, anthracite, aluminum effects, matte and gloss textures. The profile is 100% lead-free, using eco-friendly CaZn stabilizers and fully compliant with EU environmental standards. A perfect solution for terraces, conservatories, restaurants, and premium residential architecture.

Aluplast HST 85 is a modern lift-and-slide PVC system with a 197 mm frame and 85 mm sash depth. It’s specifically designed for large panoramic openings — up to 6.5 meters wide and 2.7 meters high. Slim visible profile parts and support for glazing up to 51 mm create a full "glass wall" effect with maximum natural light. The 6-chamber sash structure and Uw from 0.77 W/m²K meet the standards for energy-efficient and passive buildings. Durable EPDM seals provide reliable protection against drafts, moisture, and external noise — up to Rw 47 dB. High-performance lift-and-slide hardware allows smooth operation of sashes weighing up to 400 kg, easily operated with one hand. The system also features a low threshold starting from 20 mm, ideal for children, seniors, and accessibility needs. The PVC profile is resistant to UV, weather, deformation, and mechanical stress, with a lifespan of 40–50 years. Over 40 laminate finishes are available — including woodgrain, anthracite, aluminum effects, matte and gloss textures. The profile is 100% lead-free, using eco-friendly CaZn stabilizers and fully compliant with EU environmental standards. A perfect solution for terraces, conservatories, restaurants, and premium residential architecture.

Frame depth: 197 mm
Sash depth: 85 mm
Glass thickness: up to 51 mm
Maximum sash dimensions: 3300 × 2700 mm
Thermal insulation: Uw from 0.77 W/m²K (depending on glazing)
Air permeability: Class 4 (EN 12207)
Watertightness: Class 9A (EN 12208)
Wind load resistance: Class B3 (EN 12210)
Burglary resistance: up to RC2
Optional features: low threshold, soft-close, automation-ready

Salamander

EVOLUTION DRIVE 82

PVC

Salamander EvolutionDrive 82 is a modern lift-and-slide PVC door system designed for large glazed openings in residential and commercial buildings. The sash depth is 82 mm and the frame depth is 194 mm, providing excellent structural stability and resistance to deformation. Each sash can reach up to 3300 mm in width and 2700 mm in height. The 6-chamber profile and the option to use triple-glazed, energy-efficient units up to 52 mm thick allow the system to achieve outstanding thermal insulation — Uw from 0.77 W/m²K — and sound insulation up to Rw 45 dB, making it ideal for dense urban environments. Durable EPDM gaskets ensure tight sealing against drafts, rain, and dust. The modern HS hardware enables smooth and effortless movement of heavy sashes up to 400 kg. A low threshold option starting from 20 mm offers barrier-free access, making the system accessible for children, seniors, and people with limited mobility. The PVC profile is resistant to UV rays, moisture, and temperature extremes, with a lifespan of over 40 years. A wide selection of finishes is available, including wood-effect, matte, gloss, and Bi-Color options. Manufactured without lead, using CaZn stabilizers, the system meets strict European environmental standards. It’s a perfect choice for terraces, conservatories, balconies, and modern energy-efficient homes.

Salamander EvolutionDrive 82 is a modern lift-and-slide PVC door system designed for large glazed openings in residential and commercial buildings. The sash depth is 82 mm and the frame depth is 194 mm, providing excellent structural stability and resistance to deformation. Each sash can reach up to 3300 mm in width and 2700 mm in height. The 6-chamber profile and the option to use triple-glazed, energy-efficient units up to 52 mm thick allow the system to achieve outstanding thermal insulation — Uw from 0.77 W/m²K — and sound insulation up to Rw 45 dB, making it ideal for dense urban environments. Durable EPDM gaskets ensure tight sealing against drafts, rain, and dust. The modern HS hardware enables smooth and effortless movement of heavy sashes up to 400 kg. A low threshold option starting from 20 mm offers barrier-free access, making the system accessible for children, seniors, and people with limited mobility. The PVC profile is resistant to UV rays, moisture, and temperature extremes, with a lifespan of over 40 years. A wide selection of finishes is available, including wood-effect, matte, gloss, and Bi-Color options. Manufactured without lead, using CaZn stabilizers, the system meets strict European environmental standards. It’s a perfect choice for terraces, conservatories, balconies, and modern energy-efficient homes.

Frame depth: 194 mm
Sash depth: 82 mm
Panel thickness: up to 52 mm
Maximum sash size: 3300 × 2700 mm
Thermal insulation: Uw from 0.77 W/m²K
Air permeability: Class 4 (EN 12207)
Watertightness: Class 9A (EN 12208)
Wind load resistance: Class C3/B3 (EN 12210)
Burglar resistance: RC2 (depending on configuration)

Colors & finishes

Preview popular PVC laminates and aluminum RAL colors below. Select a sample or open the full PDF palette; final color should be confirmed against a physical swatch.

Salamander PVC

46 PVC finishes, from woodgrain textures to solid matte colors. Download PDF catalog here.
